Dhruv Metals, a Hyderabad-based India company, is a leading manufacturer and exporter of premium engineered metal products. The company, established with years of experience in metal production, serves various industries like construction, engineering, aerospace, transport, and others. Among its star products are Aluminium 6082 Bars and Rods, which are renowned for their strength, corrosion resistance, and lightweight toughness. These products are well-suited to challenging structural and mechanical applications. Supported by a guarantee of quality, prompt delivery, and economical pricing, Dhruv Metals is a reliable partner for consistent and high-performance aluminium solutions.
Aluminium 6082 Bars and Rods consist of 95.9–98.5% aluminium, 0.7–1.3% silicon, 0.7–1.3% magnesium, 0.1% copper, 0.5% manganese, and 0.25% chromium, the balance consisting of trace elements. These bars have a tensile strength of 310–410 MPa, yield strength of approximately 275 MPa, and elongation of 8–12%. The Brinell hardness is generally in the 70 to 100 HB range. This alloy is particularly suited for structural uses because of its excellent strength-to-weight ratio, good machinability, resistance to corrosion, and weldability and fabricatability, which makes it a widely applied material in all industries.
| Aluminium Alloy | ASTM B211, B211, B565, B316 5082, AMS 4121 |
| Standard | ASTM, ASME, AMS, GB/T, JIS |
| Aluminium Round Bar Temper | O, H12, H14, H16, H18, H22, H24, H26, H32, H112 |
| Aluminium Bar Form | Aluminium Round, Hex, Flat, Half Round, Oval, Rectangular in Black & Bright Finish |
| Aluminium Round Bar Diameter | 0.1-600mm,etc |
| Aluminium Hexagonal Bar | 0.1-600mm,etc |
| Aluminium Angle Bar Size | 0.5mm*40mm*40mm-20mm*400mm*400mm |
| Aluminium Flat Bar Thickness | 0.1-600mm,etc |
| Aluminium Flat Bar Size | 1-2500mm, etc |
| Aluminium Round Bar Length | 1-12m, Random, Fix & Cut Length or as per clients’ requirement |
| Aluminium Bar | Bright, Polish & Black |
| Weight% | Al | Si | Fe | Cu | Mn | Cr | Mg | Zn | Ti | Other Each | Others Total |
| Aluminium 6082 | Bal | 0.7 – 1.3 | 0.50 max | 0.10 max | 0.40-1.00 | 0.25 max | 0.06-1.20 | 0.20 max | 0.10 max | 0.05 max | 0.15 max |
| Diameter or minor sectional dimension mm | Tensile Strength, MPa | Yield Strength 0.2%, MPa | Elongation % |
| 0-20 | 295 | 255 | 8 |
| 20-150 | 310 | 270 | 8 |
| 150-200 | 280 | 240 | 5 |
| UNS | EN | DIN | ISO | BS (OLD) | USA | WNR |
| A96082 | AW-6082 | AlMgSi1 | Al Si1MgMn | HE30 | AA6082 | 3.2315 |
| Size in mm | Average Weight | |
| KG/MTR | KG/FT | |
| 10 | 0.62 | 0.18 |
| 12 | 0.90 | 0.30 |
| 14 | 1.20 | 0.40 |
| 16 | 1.60 | 0.50 |
| 18 | 2.00 | 0.60 |
| 20 | 2.50 | 0.80 |
| 22 | 3.00 | 0.90 |
| 24 | 3.56 | 1.08 |
| 25 | 3.90 | 1.20 |
| 28 | 4.80 | 1.50 |
| 30 | 5.55 | 1.69 |
| 32 | 6.30 | 1.90 |
| 34 | 7.14 | 2.18 |
| 36 | 8.00 | 2.44 |
| 40 | 9.90 | 3.00 |
| 45 | 12.49 | 3.81 |
| 50 | 15.40 | 4.70 |
| 56 | 19.34 | 5.89 |
| 60 | 22.20 | 6.80 |
| 63 | 24.47 | 7.46 |
| 63.5 | 24.86 | 7.58 |
| 65 | 26.05 | 7.94 |
| 70 | 30.20 | 9.20 |
| 73 | 32.86 | 10.00 |
| 75 | 34.72 | 10.58 |
| 78 | 37.51 | 11.43 |
| 80 | 39.50 | 12.00 |
| 83 | 42.47 | 12.95 |
| 85 | 44.55 | 13.58 |
| 90 | 50.00 | 15.20 |
| 92 | 52.19 | 15.91 |
| 93 | 53.39 | 16.27 |
| 95 | 55.65 | 16.95 |
| 100 | 61.66 | 18.79 |
| 105 | 67.98 | 20.72 |
| 110 | 74.60 | 22.74 |
| 115 | 81.64 | 24.88 |
| 125 | 96.34 | 29.36 |
Yes, Aluminium 6082 rods can be customized in size and length based on specific requirements. Manufacturers often offer custom dimensions to suit various industrial and structural applications.
Yes, Aluminium 6082 bars can be used underground due to their corrosion resistance and strength. However, proper coatings or anodization may be needed to enhance durability in highly corrosive environments.
Yes, Aluminium 6082 bars are fully recyclable. Aluminium is highly sustainable, retaining its properties through multiple recycling processes, making it an eco-friendly material for various applications.
Aluminium 6082 Rods and Bars are generally employed in structural and mechanical purposes demanding high strength, corrosion, and light weight. They are employed in bridges, support beams, and frames in building and engineering applications. Their good machinability is a strong feature for shafts, axles, and conveyor systems. The marine and aerospace industries appreciate 6082 alloy for its strength and weight savings combination, using it in aircraft parts and ship construction. Its corrosion resistance also makes it ideal for outdoor buildings and tough environments, further establishing it as one of the most popular for industrial and commercial applications.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
