Dhruv Metals is a reputable company in manufacturing and supplying Carbon Steel EN-9 Bars and Rods in Hyderabad, India. We are known for providing higher strength, wear resistance, and durability, catering to the automotive, construction, and engineering industries. Our bars of EN-9 are manufactured under strict quality control processes so that every product is of the highest industry standards. With a focus on accuracy, performance, and customer satisfaction, Dhruv Metals is your trusted associate for high-quality EN-9 carbon steel products, delivering reliable solutions for stringent mechanical and structural applications.
Carbon Steel EN-9 Bars and Rods are medium–carbon steel pieces renowned for their superior toughness and wear resistance properties. The standard composition entails Carbon (0.35–0.45%), Manganese (0.60–0.90%), with maximum restrictions of Phosphorus (0.05%) and Sulphur (0.05%). These EN-9 bars offer 650–850 MPa tensile strength and yield strength of approximately 350 MPa, good machinability, and hardenability. Because of their optimum combination of strength and workability, EN-9 bars are found to be ideal for use where good mechanical performance under heavy stress and friction is required.
| Grade | 070M55 / EN-9 |
|---|---|
| Specification | BS 970 1991 |
| Round Bar Size | Diameter: 3-~800mm |
| Square Bar size | 4 to 100mm |
| Flat Bar Size | Thickness: 2 -100mm |
| Width: 10 to 500mm | |
| Hex Bar Size | 2-100mm A/F |
| Rectangles Size | 33 x 30mm to 295 x 1066mm |
| Hollow Bar | 32mm OD x 16mm ID to 250mm OD x 200mm ID) |
| Angle Bar Size | 3mm*20mm*20mm~12mm*100mm*100mm |
| Channel Bar | 80 x 40mm to 150 x 75mm section; 5.0 to 6.0mm thickness |
| Section | 3.0 to 12.0mm thickness |
| Billet Size | 1/2″ to 495mm Diameter |
| Finish | Cold (bright) drawn, centreless ground,smooth turned, Rough Turned, Bright, peeled, hot rolled, hot rolled annealed, slit rolled edge, Polish, Grinding, Centreless Ground & Black |
| Tolerance | K9, K10, K11, K12, H8, H9, H10, H11, H12, H13, or as per clients’ requirements |
| Surface | Polished, Bright, Cold Drawn, Hot Rolled Pickled, Sand Blasting Finished, Hairline |
| Condition | Hardened & Tempered, Annealed |
| Technique | en9 Hot Rolled, Cold Rolled, Cold Drawn, Forged Round Bar, Rods |
| Processing | Bar cutting to 650mm |
| Form | en9 Welding Rod, Round, Round Rod, Rings, Hollow, Rod, T-Bar, Channel Bar, Flat Bar, Square, Blocks, Precision Ground Bar, Triangle, Rectangle, Hex (A/F), Threaded, Ingot, I/H Bar, Half Round Bar, Profiles, Billet, Forging etc. |
| EN9 / 070M55 Bars and Rods Conforms To NACE MR0175/ISO 15156 | |
| Grade | Cr | C | Ni | Si | S | Mn | P | Mo |
| EN – 9 | – | .50 – .60 | – | .05 – .35 | .040 MAX | .50 – .80 | .040 MAX | – |
| Heat Treatment | Condition Tons/SQ.inch | Tensile Stress RE MPA | RP0.2 MPA | A min on 5.65so | Impac | Hardness HB | Limited Ruling Section mm | |
| IZODFT.L.b | KCV Joules | |||||||
| Normalise | 45 | 700 | – | 12 | – | – | 201-255 | 63 |
| 39 | 600 | – | 13 | – | – | 170/223 | 250 | |
| R | 45/55 | 700/850 | 385 | 14 | – | – | 201/277 | 100 |
| S | 50/60 | 775/925 | 450 | 14 | – | – | 223/277 | 63 |
| T | 55/65 | 850/1000 | 555 | 12 | – | – | 248/302 | 19 |
| Standard | CS EN-9 |
| UNS | – |
| WERKSTOFF NR. | CK55 |
| BS | 070M55 |
| IS | C55 |
| JIS | – |
| EN | EN9 |
| SAE/AISI | 1055 |
Carbon Steel EN-9 is commonly used for manufacturing bolts, nuts, fasteners, and structural components in heavy-duty applications like automotive and construction industries.
EN-9 offers excellent tensile strength, wear resistance, and hardenability, making it suitable for components subjected to mechanical stresses and heavy-duty environments.
Yes, Carbon Steel EN-9 can be heat-treated to enhance its hardness and strength, making it versatile for various engineering applications.
EN-9 Carbon Steel Bars and Rods are preferred for parts where strength, toughness, and wear resistance are of paramount importance. Typical uses are in bolts, nuts, couplings, fasteners, and gears—components that are subjected to repeated mechanical stress. They are also extensively used in farm equipment, structural components, and engineering parts. Hardenability and versatility qualify them for uses in industries such as automotive, construction, and general engineering, where consistency of performance under heavy-duty applications is required. EN-9 provides a working compromise of affordability and mechanical integrity that makes it an industrial workhorse for long-term use.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
