Dhruv Metals, based in Hyderabad, India, stands out as a top-notch manufacturer and supplier of high-quality Hastelloy C22 forgings. With a strong focus on engineering excellence and ensuring customer satisfaction, Dhruv Metals provides precision-forged components that adhere to global standards, including ASTM and ASME specifications. The company excels in crafting high-performance forgings like rings, discs, shafts, and custom shapes tailored for critical applications. Supported by cutting-edge technology and rigorous quality control, Dhruv Metals caters to various industries such as chemical processing, marine, pharmaceuticals, and power generation, delivering solutions that guarantee durability, corrosion resistance, and top-notch performance in even the toughest environments.
Hastelloy C22 is a nickel-chromium-molybdenum alloy known for its exceptional corrosion resistance. Its typical makeup consists of 56% nickel, 20–22.5% chromium, 12.5–14.5% molybdenum, 2.5–3.5% tungsten, along with trace amounts of iron, cobalt, and other elements. This alloy showcases impressive mechanical properties, boasting a tensile strength of around 690 MPa, a yield strength of about 310 MPa, and an elongation exceeding 45%. It provides remarkable resistance to pitting, crevice corrosion, and stress corrosion cracking, even in harsh oxidizing and reducing environments. Hastelloy C22 retains its strength and ductility across a broad temperature range, making it perfect for demanding industrial applications.
Specifications ASTM B564 / ASME SB564
Flat bar blocks up to 27″ width and 15,000 lbs.
Cylinders and sleeves up to 50″ maximum O.D. and 65″ maximum length
Discs and hubs up to 50″ diameter and 20,000 lbs.
Rolled, hand forged or mandrel forged rings up to 84″ maximum O.D. and 40″ maximum length
Rounds, shafts and step shafts up to 144″ maximum length and 20,000 lbs.
Grades Hastelloy C22 Forging UNS (N06022), DIN (2.4602)
| Grade | Ni | C | Mo | Mn | Si | Fe | P | S | Co | Cr | W | V |
| Hastelloy C22 | Balance | 0.010 max | 12.5-14.5 | 0.50 max | 0.08 max | 2-6 | 0.02 max | 0.02 max | 2.5 max | 20-22.5 | 2.5-3.5 | 0.35 max |
| Grade | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Hastelloy C22 | 8.69 g/cm3 | 1399 °C (2550 °F) | Psi – 1,00,000, MPa – 690 | Psi – 45000, MPa – 310 | 45 % |
| STANDARD | UNS | WNR. | AFNOR | EN | JIS |
| Hastelloy C22 | N06022 | 2.4602 | – | NiCr21Mo14W | NW 6022 |
Yes, Hastelloy C22 can be forged into custom shapes, as it has good formability and strength at elevated temperatures. However, it requires precise control during the forging process to maintain its properties.
The ideal temperature range for forging Hastelloy C22 is between 2,100°F (1,150°C) and 2,300°F (1,260°C). This ensures optimal formability and minimizes the risk of damaging the material's properties.
The forging process for Hastelloy C22 typically takes several minutes to hours, depending on the complexity and size of the part. The heating and cooling cycles also influence the total time required for forging.
Hastelloy C22 forgings find extensive use in industries dealing with highly corrosive materials. Typical applications include chemical reactors, heat exchangers, valves, and pumps within the chemical processing and petrochemical fields. The alloy’s ability to withstand strong oxidizers and reducing agents makes it ideal for flue gas scrubbers, waste treatment systems, and acid manufacturing. Additionally, it is utilized in marine settings, pharmaceutical production, and nuclear waste processing.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
