Dhruv Metals, located in Hyderabad, India, stands out as a top manufacturer and supplier of high-performance Inconel 617 Bars and Rods. We cater to industries where strength, oxidation resistance, and stability at high temperatures are crucial. Our Inconel 617 products are made from high-quality raw materials and cutting-edge manufacturing techniques, ensuring they are accurate in dimensions, durable, and consistently perform well. These bars and rods are widely utilized in sectors like aerospace, chemical processing, and power generation, all while meeting international quality standards. At Dhruv Metals, we are dedicated to providing Inconel 617 Bars and Rods that you can rely on, even in the toughest high-temperature and corrosive environments.
Inconel 617 Bars and Rods are primarily made of nickel, with significant amounts of chromium, cobalt, and molybdenum added. This unique alloy offers exceptional resistance to oxidation and carburization at elevated temperatures, along with impressive creep strength and good weldability. The blend of strength and corrosion resistance allows Inconel 617 to thrive in harsh thermal and chemical conditions, all while maintaining its structural integrity and mechanical properties over time.
| Standards | ASTM B166, ASME SB 166, AMS 5887 |
|---|---|
| Specifications | DIN, EN, ASTM, JIS, ASME, BS, AISI |
| 617 Inconel Round Bars size | Diameter: 3-~800mm |
| Inconel 617 Flat Bars size | Thickness: 2 -100mm |
| Width: 10 to 500mm | |
| Inconel 617 Angle Bars size | 3mm*20mm*20mm~12mm*100mm*100mm |
| Inconel 617 Channel Bars | 80 x 40mm to 150 x 75mm section; 5.0 to 6.0mm thickness |
| Alloy 617 Rectangular Bars Section | 3.0 to 12.0mm thickness |
| Inconel 617 Billet Size | 1/2 to 495mm Diameter |
| Inconel 617 Rectangle Bar Size | 33 x 30mm to 295 x 1066mm |
| Inconel 617 Hex Bar size | 2-100mm A/F |
| Inconel 617 Hollow Bars | 32mm OD x 16mm ID to 250mm OD x 200mm ID) |
| Diameter | 20mm, 30mm, 50mm, 80mm, 100mm, 150mm, 200mm, 500mm |
| Length | 1m-12m or as required |
| Tolerance | H8, H9, H10, H11, H12, H13K9, K10, K11, K12 or as per clients’ requirements |
| Finish | hot rolled annealed, peeled, Bright, hot-worked and cold-worked rod and bar, centreless ground, Centreless Ground and Black, Polish, Cold Rolled (CR), hot rolled ( R), smooth turned, Cold (bright) drawn, Grinding, slit rolled edge, Rough Turned. |
| Surface | Hot Rolled Pickled, Bright, Sand Blasting Finished, Cold Drawn, Hairline,Polished |
| Condition | Hardened & tempered, annealed |
| Technique | Cold Drawn, Hot Rolled, Forged Round Bars, Cold Rolled, Rod |
| Processing | Bars cutting to 650mm |
| Form | Rod, Round, Channel Bars, T-Bars, Flat Bars, Precision Ground Bars, Blocks, Square, Round Rod, Triangle, Hollow, Rectangle, Threaded, Hex (A/F), Profiles, Half Round Bars, Ingot, Billet, I/H Bars, Forging etc. |
| STANDARD | WERKSTOFF NR. | UNS |
| Inconel 617 | 2.4663 | N06617 |
| Grade | Ni | Cr | Fe | C | Mn | S | Mo | Si | Co |
| Inconel 617 | 48.85 – 62 | 20 – 24.0 | Balance | ≤ 0.15 | ≤ 1 | – | 8 – 10 | ≤ 1 | 10-15 |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 8.3g/cm³ | 1363°C | ≥ 485 MPa | ≥ 275 MPa | 25 % |
Yes, Inconel 617 Bars/Rods are designed to perform exceptionally well in high-temperature environments up to 980°C.
Yes, they can be tailored in terms of size, dimensions, and specifications to meet specific industrial requirements.
Yes, we provide bars and rods in standard and customized dimensions and polishes to meet your specific project requirements. For more details mail us on sales@dhruvmetals.co.in
These Inconel 617 Bars and Rods find extensive use in applications such as gas turbines, heat exchangers, combustors, and components in high-temperature chemical processing systems. They are also perfect for power plant components, including superheater tubes and reheater tubing, where they face prolonged exposure to heat and corrosion. Thanks to the alloy’s ability to resist thermal degradation and mechanical fatigue, it’s an ideal choice for demanding industrial environments. Dhruv Metals provides Inconel 617 Bars and Rods that are engineered for long-lasting reliability and exceptional performance in extreme service conditions.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Dhruv Metals is a leading manufacturer, supplier, and exporter of high-quality bars, rods, and forgings, catering to various industries in Hyderabad , India
