Dhruv Metals, based in Hyderabad, India, is a trusted name in the manufacturing and supply of top-quality Inconel Bright Bars, serving a diverse array of industrial sectors both at home and abroad. Our Inconel Bright Bars are celebrated for their impressive strength, resistance to corrosion, and outstanding finish. We produce these bars using cutting-edge techniques and rigorous quality control, ensuring they excel in demanding environments that face extreme temperatures and chemical exposure. At Dhruv Metals, we guarantee that every Inconel Bright Bar offers exceptional performance, precision, and durability, making us a reliable partner for industries such as aerospace, marine, power generation, and chemical processing.
These Inconel Bright Bars are primarily made from nickel and chromium, often combined with elements like molybdenum, iron, cobalt, and niobium, depending on the specific grade (like Inconel 600, 625, or 718). This unique blend provides remarkable resistance to oxidation, corrosion, and high-temperature strength. On a mechanical level, Inconel Bright Bars boast high tensile and yield strength, outstanding creep resistance, and solid fatigue strength. Their bright surface finish not only enhances machinability and visual appeal but also ensures they perform well in harsh environments.
| Ni | Cr | Fe | Mo | Nb+Ta | C | Mn | Si | Ph | S | Al | Ti | Co | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Min | Bal | 20 | – | 8 | 3.15 | – | – | – | – | – | – | – | – |
| Max | – | 23 | 5 | 10 | 4.15 | 0.10 | 0.50 | 0.50 | 0.015 | 0.015 | 0.40 | 0.40 | 1.0 |
| 0.2% Proof Stress | Tensile Strength | Elongation | Reduction of area | Hardness |
|---|---|---|---|---|
| MPA | MPA | % | % | HRB |
| Min | Min | Min | Min | Min |
| 414 | 827 | 30 | 40 | 145 |
| Size (mm) | Weight (kg/m) | Size (mm) | Weight (kg/m) | Size (mm) | Weight (kg/m) |
|---|---|---|---|---|---|
| 7 x 7 | 0.337 | 19 x 19 | 2.479 | 38 x 38 | 9.916 |
| 8 x 8 | 0.44 | 20 x 20 | 2.747 | 40 x 40 | 10.988 |
| 9 x 9 | 0.556 | 21 x 21 | 3.029 | 42 x 42 | 12.114 |
| 10 x 10 | 0.687 | 22 x 22 | 3.324 | 45 x 45 | 13.906 |
| 11 x 11 | 0.831 | 24 x 24 | 3.956 | 48 x 48 | 15.822 |
| 12 x 12 | 0.989 | 25 x 25 | 4.292 | 50 x 50 | 17.168 |
| 13 x 13 | 1.161 | 26 x 26 | 4.642 | 53 x 53 | 19.29 |
| 14 x 14 | 1.346 | 28 x 28 | 5.384 | 55 x 55 | 20.774 |
| 15 x 15 | 1.545 | 30 x 30 | 6.181 | 60 x 60 | 24.723 |
| 16 x 16 | 1.758 | 32 x 32 | 7.032 | 65 x 65 | 29.015 |
| 17 x 17 | 1.985 | 34 x 34 | 7.939 | 70 x 70 | 33.65 |
| 18 x 18 | 2.225 | 36 x 36 | 8.9 | 75 x 75 | 38.629 |
Yes, Inconel bright bars are suitable for hygienic and sanitary applications due to their excellent corrosion resistance and ease of cleaning. They are commonly used in industries such as food processing, pharmaceuticals, and healthcare.
Yes, we provide bars and rods in standard and customized dimensions and polishes to meet your specific project requirements. For more details mail us on sales@dhruvmetals.co.in
Inconel Bright Bars find extensive applications in high-temperature and high-pressure settings across various industries, including aerospace for engine components, marine for seawater systems, nuclear reactors, heat exchangers, gas turbines, and chemical processing equipment. Their superior resistance to oxidation and corrosive substances makes them perfect for challenging service conditions. Plus, they are suitable for cryogenic applications due to their structural integrity at low temperatures. Dhruv Metals delivers Inconel Bright Bars designed to perform reliably in complex environments, where material failure simply isn’t an option.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
