Dhruv Metals, based in Hyderabad , India, is a leading manufacturer and supplier of high-quality metal products used in various industrial applications. Known for precision, reliability, and innovation, Marcus produces stainless solutions such as the versatile 15-5 PH hex bars and rods. Due to their immense strength plus great resistance to corrosion and durability, these stainless steel items are used on aerospace, marine, and engineering fields. As a fully committed company to quality, Marcus ensures that its products exceed even the strictest quality checks while providing customized solutions whenever needed for its broad spectrum of customers in the India and beyond.
Stainless Steel 15-5 PH hex bars and rods are the martensitic precipitation-hardening alloys, approximately containing 15% Chromium, 4-5% Nickel, 3-5% Copper, 0.05% Carbon, 0.15-0.45% Manganese, trace Silicon, Phosphorus, and Sulfur. They are especially known for very high strength and toughness with significant corrosion resistance as well. Tensile strengths of 930-1170 MPa, yield strengths of 865 MPa, and elongation from 14 to 16% in the H900 condition describe their mechanical properties. Their hardness ranges between 38-42 HRC, making them suitable for demanding applications in aerospace, marine, and industrial environments requiring excellent mechanical stability and corrosion resistance under extreme conditions.
Dimensions : ASTM, ASME
Standard : ASTM / ASME SA A276, A479, ASTM A493
Length : Random, Fix & Cut Length
Size : 20MM to 150MM
| Grade | C | Cb+Ta | Cr | Cu | Fe | Mn | Ni | P | S | Si |
| SS 15-5 PH | 0.07 max | 0.15-0.45 max | 14.0-15.0 max | 2.5-4.5 max | Bal | 1.0 | 3.5-5.5 | 0.04 | 0.03 | 1.0 |
| Grade | Tensile Strength ksi (MPa) | Yield Strength 0.2% ksi (min) | Elongation % | Hardness (Rockwell) MAX |
| SS 15-5 PH | 161,000 | 140,000 | 7.6% | C35 |
| STANDARD | WERKSTOFF NR. | UNS |
| SS 15-5PH | 1.4545 | S15500 |
| HEXAGONS | ||
| Size(mm) | WT PER FEET IN KGS | WT PER MTR IN KGS |
| 16 | 0.55 | 1.79 |
| 18 | 0.69 | 2.27 |
| 20 | 0.85 | 2.80 |
| 22 | 1.03 | 3.39 |
| 25 | 1.33 | 4.38 |
| 28 | 1.67 | 5.49 |
| 30 | 1.92 | 6.30 |
| 32 | 2.19 | 7.17 |
| 36 | 2.77 | 9.07 |
| 38 | 3.08 | 10.11 |
| 40 | 3.41 | 11.20 |
| 45 | 4.32 | 14.18 |
| 50 | 5.34 | 17.50 |
| 56 | – | – |
| 60 | – | – |
| 65 | – | – |
| 70 | – | – |
| 75 | – | – |
| 80 | – | – |
| 90 | – | – |
| 100 | – | – |
Store Stainless Steel 15-5 PH hex bars and rods in a clean, dry, ventilated area, elevated on racks, with protective covers, separated from other metals, and handled carefully.
Stainless Steel 15-5 PH hex bars excel in wear-resistant applications due to their high strength, toughness, excellent corrosion resistance, and ability to maintain hardness after precipitation-hardening heat treatment.
Common challenges with Stainless Steel 15-5 PH hex bars include susceptibility to stress corrosion cracking in chloride environments, limited ductility in hardened conditions, higher machining difficulty, and potential distortion during heat treatment.
Stainless Steel 15-5 PH hex bars and rods have wide application in industries demanding strength, corrosion resistance, and high durability. Among the more typical applications, the list is extended to include gears, shafts, structural parts, marine hardware, which enjoy excellent resistance to stress corrosion cracking, and even chemical processing equipment, medical instruments, and high-performance valves. In the automotive industry, they are used in precision-engineered parts, such as those in transmissions. Their superior mechanical properties make them ideal for the manufacture of parts that are under high loads. Their stability under harsh environments guarantees reliability in critical applications.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Dhruv Metals is a leading manufacturer, supplier, and exporter of high-quality bars, rods, and forgings, catering to various industries in Hyderabad , India
