Dhruv Metals, located in Hyderabad, India, stands out as a top manufacturer and supplier of Stainless Steel 304L Hex Bars and Rods. They provide high-quality solutions for industries that require materials with excellent corrosion resistance, durability, and formability. Their SS 304L hex bars are crafted in line with ASTM A276 standards, making them renowned for their superb weldability, smooth finish, and precise dimensions. Dhruv Metals caters to a variety of sectors, including food processing, pharmaceuticals, petrochemicals, and construction, offering customized products designed to meet specific industrial requirements. With a reputation for reliable service, competitive pricing, and a strong dedication to quality, Dhruv Metals has become a trusted name in stainless steel supply both nationally and internationally.
Stainless Steel 304L is a low-carbon variant of 304, containing about 18–20% chromium and 8–12% nickel, with a maximum carbon content of 0.03%. This unique composition boosts its corrosion resistance, particularly after welding, by minimizing carbide precipitation. It boasts a tensile strength of around 485 MPa, a yield strength of about 170 MPa, and an elongation of roughly 40%. The alloy is known for its excellent weldability, formability, and mechanical strength, all while retaining its non-magnetic properties. These features make SS 304L hex bars ideal for fabrication and applications where cleanliness and corrosion resistance are essential.
Dimensions : ASTM, ASME
Standard : ASTM / ASME SA A276, A479, ASTM A493
Length : Random, Fix & Cut Length
Size : 20MM to 150MM
| Element | C | Cr | Mn | Ni | P | S | Si |
| SS 304L | 8.0 – 11.0 | 18.0 – 20.0 | 2.0 max | 8.0 – 12.0 | 0.045 max | 0.03 max | 1.0 max |
| Element | C | Cr | Mn | Ni | P | S | Si |
| SS 304L | 8.0 – 11.0 | 18.0 – 20.0 | 2.0 max | 8.0 – 12.0 | 0.045 max | 0.03 max | 1.0 max |
| Element | Density, lb/in3 | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| SS 304L | 8.0 g/cm3 | 1400 °C (2550 °F) | 485 | 170 | 40 |
| HEXAGONS | ||
|---|---|---|
| Size(mm) | WT PER FEET IN KGS | WT PER MTR IN KGS |
| 16 | 0.55 | 1.79 |
| 18 | 0.69 | 2.27 |
| 20 | 0.85 | 2.80 |
| 22 | 1.03 | 3.39 |
| 25 | 1.33 | 4.38 |
| 28 | 1.67 | 5.49 |
| 30 | 1.92 | 6.30 |
| 32 | 2.19 | 7.17 |
| 36 | 2.77 | 9.07 |
| 38 | 3.08 | 10.11 |
| 40 | 3.41 | 11.20 |
| 45 | 4.32 | 14.18 |
| 50 | 5.34 | 17.50 |
| 56 | – | – |
| 60 | – | – |
| 65 | – | – |
| 70 | – | – |
| 75 | – | – |
| 80 | – | – |
| 90 | – | – |
| 100 | – | – |
SS 304L hex bars/rods are typically available in sizes ranging from 3.17mm to 350mm in diameter, with lengths of 2 to 7.5 meters. These bars come in various finishes, such as polished or cold-drawn. Custom sizes and specifications can also be produced upon request to meet specific needs.
Yes, SS 304L hex bars/rods are highly weldable and suitable for fabrication into complex shapes. Their low carbon content minimizes carbide precipitation during welding, reducing the risk of corrosion. This material's excellent ductility and toughness allow easy forming, machining, and fabrication, making it ideal for intricate designs and applications.
SS 304L has lower carbon content than standard 304, reducing carbide precipitation and enhancing corrosion resistance, particularly after welding. While slightly lower in strength compared to higher-carbon grades like 304 or 316, it maintains excellent toughness and durability. SS 316 offers superior corrosion resistance in chloride environments due to added molybdenum.
Stainless Steel 304L Hex Bars and Rods find extensive use in applications that demand outstanding corrosion resistance, easy machinability, and clean surface finishes. In the food and beverage sector, they are commonly used in processing equipment and kitchen fittings due to their sanitary qualities. The pharmaceutical and chemical industries depend on them for reactors, pipelines, and tanks that face moderate corrosive environments. In construction and architecture, SS 304L hex bars are utilized for decorative elements, railings, and structural components. They also play a role in heat exchangers, marine hardware, and automotive parts. Thanks to their low carbon content, they are particularly well-suited for these diverse applications.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
