Dhruv Metals, located in Hyderabad, India, stands out as a top manufacturer and supplier of Stainless Steel 316 Square Bars and Rods. These products are celebrated for their exceptional corrosion resistance, strength, and durability. Stainless Steel 316 is an austenitic alloy that includes molybdenum, which significantly boosts its resistance to pitting and crevice corrosion, particularly in environments rich in chlorides. At Dhruv Metals, we take pride in producing SS 316 square bars and rods with precise dimensions and consistent quality, making them perfect for a variety of industries, including marine, chemical, pharmaceutical, and food processing.
Our Stainless Steel 316 Square Bars and Rods are made up of chromium (16.0–18.0%), nickel (10.0–14.0%), molybdenum (2.0–3.0%), and carbon (≤0.08%), along with trace amounts of manganese, silicon, phosphorus, and sulfur. These bars boast a tensile strength of around 515 MPa, a yield strength of 205 MPa, an elongation of 40%, and a Brinell hardness of up to 217 HB. The inclusion of molybdenum enhances the alloy’s capability to endure acidic and saline conditions while retaining excellent mechanical properties.
Dimensions : ASTM, ASME
Standard : ASTM / ASME SA A582, A276, A564, ASTM A484, 484M
Surface : hrap, hot rolled pickled or sand blasting finished, cold drawn, polished, hairline
Size : Tolerance: H8, H9, H10, H11, H12, H13K9, K10, K11, K12
| Element | C | Cr | Mn | Ni | P | S | Si |
| SS 316 | 0.08 | 18.0 | 2.00 | 14.0 | 0.045 max | 0.03 max | 0.75 max |
| Element | Density, lb/in3 | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| SS 316 | – | – | 515 Min | 205 Min | 40% Min |
| STANDARD | WERKSTOFF NR. | UNS | JIS | BS | GOST | AFNOR | EN |
| SS 316 | 1.4401 / 1.4436 | S31600 | SUS 316 | 316S31 / 316S33 | – | Z7CND17‐11‐02 | X5CrNiMo17-12-2 / X3CrNiMo17-13-3 |
| SQUARES | ||
|---|---|---|
| Size(mm) | WT PER FEET IN KGS | WT PER MTR IN KGS |
| 16 | 0.62 | 2.05 |
| 18 | 0.79 | 2.59 |
| 20 | 0.76 | 2.49 |
| 22 | 1.18 | 3.87 |
| 25 | 1.52 | 5.00 |
| 28 | 1.91 | 6.27 |
| 30 | 2.19 | 7.20 |
| 32 | 2.50 | 8.19 |
| 36 | 3.16 | 10.37 |
| 38 | 3.52 | 11.55 |
| 40 | 3.90 | 12.80 |
| 45 | 4.94 | 16.20 |
| 50 | 6.10 | 20.00 |
| 56 | 7.65 | 25.08 |
| 60 | – | – |
| 65 | – | – |
| 70 | – | – |
| 75 | – | – |
| 80 | – | – |
| 90 | – | – |
| 100 | – | – |
Stainless Steel 316 square bars are resistant to galvanic corrosion when used in environments with similar metals. However, when coupled with dissimilar metals, they can be susceptible to galvanic corrosion if exposed to electrolytes.
Stainless Steel 316 square rods are available in various sizes ranging from 1/8" to 6" or more, depending on the supplier. They are typically offered in finishes such as mill, polished, or brushed, based on customer requirements.
Yes, Stainless Steel 316 square bars are highly resistant to corrosion, making them suitable for underground applications. Their durability and resistance to rust make them ideal for use in harsh environments.
Stainless Steel 316 Square Bars and Rods are commonly utilized in applications that require high corrosion resistance and structural integrity. Typical applications include marine hardware, food-grade equipment, chemical tanks, valves, fasteners, and architectural frameworks. Their square shape lends strength and stability to load-bearing components and machined parts. SS 316 is particularly well-suited for coastal, industrial, and hygienic settings where exposure to corrosive substances is a regular occurrence. With outstanding weldability, formability, and long-lasting durability, SS 316 square bars and rods are a reliable choice for critical and precision-engineered applications.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
