Dhruv Metals, located in Hyderabad, India, has earned a solid reputation as a reliable manufacturer and supplier of Stainless Steel 316L Hex Bars and Rods. These products are celebrated for their outstanding corrosion resistance, excellent weldability, and adaptability in challenging environments. Stainless Steel 316L is a low-carbon variant of SS 316, which provides improved resistance to sensitization during welding and prolonged exposure to corrosive substances. At Dhruv Metals, we take pride in our precisely manufactured SS 316L hex bars and rods, which adhere to international standards and serve critical industries like marine, pharmaceuticals, chemical processing, and food manufacturing.
The composition of Stainless Steel 316L Hex Bars and Rods includes chromium (16.0–18.0%), nickel (10.0–14.0%), molybdenum (2.0–3.0%), and carbon (≤0.03%), along with trace amounts of manganese, silicon, phosphorus, and sulfur. These bars boast a tensile strength of around 485 MPa, a yield strength of 170 MPa, an elongation of 40%, and a Brinell hardness of up to 217 HB. The inclusion of molybdenum enhances resistance to pitting and crevice corrosion, especially in chloride-rich and acidic environments, while the low carbon content ensures strong weld integrity.
Dimensions : ASTM, ASME
Standard : ASTM / ASME SA A276, A479, ASTM A493
Length : Random, Fix & Cut Length
Size : 20MM to 150MM
| Element | C | Cr | Mn | Ni | P | S | Si |
| SS 316l | 0.08 | 18.0 | 2.00 | 14.0 | 0.045 max | 3.00 max | 0.10 max |
| Element | C | Cr | Mn | Ni | P | S | Si |
| SS 316l | 0.08 | 18.0 | 2.00 | 14.0 | 0.045 max | 3.00 max | 0.10 max |
| HEXAGONS | ||
|---|---|---|
| Size(mm) | WT PER FEET IN KGS | WT PER MTR IN KGS |
| 16 | 0.55 | 1.79 |
| 18 | 0.69 | 2.27 |
| 20 | 0.85 | 2.80 |
| 22 | 1.03 | 3.39 |
| 25 | 1.33 | 4.38 |
| 28 | 1.67 | 5.49 |
| 30 | 1.92 | 6.30 |
| 32 | 2.19 | 7.17 |
| 36 | 2.77 | 9.07 |
| 38 | 3.08 | 10.11 |
| 40 | 3.41 | 11.20 |
| 45 | 4.32 | 14.18 |
| 50 | 5.34 | 17.50 |
| 56 | – | – |
| 60 | – | – |
| 65 | – | – |
| 70 | – | – |
| 75 | – | – |
| 80 | – | – |
| 90 | – | – |
| 100 | – | – |
SS 316L Hex Bars/Rods offer exceptional resistance to corrosion, including pitting and crevice corrosion caused by chlorides, due to their chromium and molybdenum content. Their low carbon levels prevent sensitization, ensuring durability in marine and chemical environments.
SS 316L Hex Bars/Rods are used in marine, chemical processing, food, pharmaceutical, and oil and gas industries. Their superior corrosion resistance enhances longevity and performance, particularly in environments exposed to chlorides, acids, alkalis, and high-moisture conditions.
Yes, SS 316L Hex Bars/Rods are easily welded and machined due to their low carbon content. However, precautions include using appropriate tools to avoid work hardening, maintaining low heat input during welding, and employing post-weld cleaning to prevent contamination.
Stainless Steel 316L Hex Bars and Rods are commonly utilized in settings that demand both high corrosion resistance and clean surface finishes. Typical applications include marine components, pharmaceutical processing equipment, chemical tanks, heat exchangers, and food-grade machinery. Their hexagonal shape makes them perfect for creating fasteners, bolts, and precision-machined parts. SS 316L is particularly well-suited for cleanrooms, surgical environments, and coastal or submerged conditions, where hygiene, corrosion resistance, and durability are essential. Its excellent formability and resistance to contamination make it a go-to material across various industrial sectors.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
