Located in Hyderabad, India, Dhruv Metals is a top producer and supplier of premium stainless steel 416 flat bars, which are well-known for their exceptional strength, machinability, and resistance to corrosion. Dhruv Metals, which specialises in finely crafted stainless steel products, provides flat bars in a range of sizes and finishes to satisfy the various needs of general engineering, automotive, and aerospace industries. With an emphasis on meeting international quality standards and providing dependable performance, the company makes sure every product is produced utilising cutting-edge methods and stringent testing. In India and overseas, Dhruv Metals is dedicated to providing prompt delivery, affordable prices, and customer-focused service.
Chromium (12–14%), carbon (0.15%), manganese (1.25%), silicon (1%), sulphur (0.15–0.35%), and iron make up the base of the martensitic, free-machining stainless steel known as Stainless Steel 416 Flat Bar. Sulphur greatly improves machinability. It has a 15% elongation, a 275–500 MPa yield strength, and a 550–760 MPa tensile strength. Particularly after heat treatment, 416 shows good hardness and moderate corrosion resistance. Its exceptional machinability makes it perfect for precision manufacturing and high-speed machining operations, even though it is not as corrosion-resistant as austenitic grades.
Dimensions : ASTM, ASME
Standard : ASTM / ASME SA A582, A276, A564, ASTM A484, 484M
Surface : hrap, hot rolled pickled or sand blasting finished, cold drawn, polished, hairline
Range : Range – 3.17mm to 350mm dia
| Element | C | Cr | Mn | Ni | P | S | Si |
| SS 416 | 0.15 | 14.0 – 12.0 | 1.25 | – | 0.06 | 0.15 | 1 |
| Element | Density, lb/in3 | Melting Point | Electrical Resistivity |
| SS 416 | 0.282 lbs/in3 7 .80 g/cm3 | 2700 – 2790 °F (1488 – 1530 °C) | At 70 °F (21 °C): 343.0 |
| Flat Bar | ||
|---|---|---|
| Size(mm) | WT PER FEET IN KGS | WT PER MTR IN KGS |
| 16 | 0.49 | 1.60 |
| 18 | 0.62 | 2.02 |
| 20 | 0.76 | 2.49 |
| 22 | 0.92 | 3.02 |
| 25 | 1.19 | 3.90 |
| 28 | 1.49 | 4.89 |
| 28 | 1.49 | 4.89 |
| 30 | 1.71 | 5.61 |
| 32 | 1.95 | 6.38 |
| 36 | 2.46 | 8.08 |
| 38 | 2.74 | 9.00 |
| 40 | 3.04 | 9.97 |
| 45 | 3.85 | 12.62 |
| 50 | 4.75 | 12.62 |
| 56 | 8.96 | 19.55 |
| 60 | 6.84 | 22.44 |
| 65 | 8.03 | 26.34 |
| 70 | 9.31 | 30.54 |
| 75 | 10.69 | 35.06 |
| 80 | 12.16 | 39.89 |
| 90 | 15.39 | 50.49 |
| 100 | 19 | 62.34 |
Applications needing good mechanical strength, moderate corrosion resistance, and high machinability frequently use stainless steel 416 flat bars. They are widely used in the automotive industry to manufacture fasteners, shafts, axles, and gears. They are utilised for precision-engineered parts that need strict tolerances in the defence and aerospace industries. In water treatment and industrial fluid handling systems, 416 flat bars are also used in pumps, valves, and fittings. They are appropriate for high-volume production of parts in general engineering, medical devices, and instrumentation due to their ease of machining. They are also employed in the production of appliances and hardware in the country.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
