Dhruv Metals, located in Hyderabad, India, is a well-known manufacturer and supplier of top-notch Stainless Steel 440C Hex Bars. Our 440C hex bars are celebrated for their exceptional hardness, wear resistance, and strength, making them perfect for high-performance and precision-critical applications. Stainless Steel 440C is a high-carbon martensitic stainless steel grade that can be heat-treated to achieve remarkable hardness and edge retention. At Dhruv Metals, we pride ourselves on providing consistent, high-strength stainless steel hex bars to a variety of industries both in India and around the globe.
These Stainless Steel 440C Hex Bars are made up of high carbon (0.95–1.20%) and high chromium content (16.0–18.0%), along with trace amounts of manganese (≤1.0%), silicon (≤1.0%), optional molybdenum, phosphorus (≤0.040%), and sulfur (≤0.030%). This unique composition allows 440C to reach an impressive hardness after heat treatment—up to 58–60 HRC. It also boasts a tensile strength of 760–1970 MPa, a yield strength of about 450 MPa, and moderate corrosion resistance. With its excellent hardness, wear resistance, and moderate corrosion resistance, 440C stands out as one of the hardest stainless steels available in bar form.
Dimensions : ASTM, ASME
Standard : ASTM / ASME SA A276, A479, ASTM A493
Length : Random, Fix & Cut Length
Size : 20MM to 150MM
| Element | C | Cr | Mn | Ni | P | S | Si |
| SS 440C | 1.20-0.95 | 18.00-16.00 | 1.00 | 1.00 | 0.04 | 0.03-0.15 | 1.00 |
| Element | C | Cr | Mn | Ni | P | S | Si |
| SS 440C | 1.20-0.95 | 18.00-16.00 | 1.00 | 1.00 | 0.04 | 0.03-0.15 | 1.00 |
| HEXAGONS | ||
|---|---|---|
| Size(mm) | WT PER FEET IN KGS | WT PER MTR IN KGS |
| 16 | 0.55 | 1.79 |
| 18 | 0.69 | 2.27 |
| 20 | 0.85 | 2.80 |
| 22 | 1.03 | 3.39 |
| 25 | 1.33 | 4.38 |
| 28 | 1.67 | 5.49 |
| 30 | 1.92 | 6.30 |
| 32 | 2.19 | 7.17 |
| 36 | 2.77 | 9.07 |
| 38 | 3.08 | 10.11 |
| 40 | 3.41 | 11.20 |
| 45 | 4.32 | 14.18 |
| 50 | 5.34 | 17.50 |
| 56 | – | – |
| 60 | – | – |
| 65 | – | – |
| 70 | – | – |
| 75 | – | – |
| 80 | – | – |
| 90 | – | – |
| 100 | – | – |
Heat treatment of SS 440C involves hardening by quenching and tempering, significantly increasing hardness and wear resistance. Proper heat treatment also enhances corrosion resistance, making the material suitable for demanding applications.
SS 440C Hex Bar is commonly used in bearings, shafts, valves, and tools. Its high hardness, wear resistance, and moderate corrosion resistance make it preferred over other stainless steels for demanding, high-strength applications.
Stainless Steel 440C Hex Bars find their place in applications that demand maximum hardness and wear resistance, such as bearings, valve components, surgical instruments, cutting tools, and high-end knife blades. These bars are extensively utilized in aerospace, defense, and precision engineering sectors where strength, dimensional stability, and abrasion resistance are crucial. Additionally, 440C is perfect for molds, dies, and industrial equipment that operate under high-stress or abrasive conditions. Thanks to its high carbon content, it performs best in dry or mildly corrosive environments where maximum edge retention and hardness are top priorities.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
