Based in Hyderabad, India, Dhruv Metals is a reputable producer and supplier of premium stainless steel forged bars and rods that are prized for their durability, strength, and accuracy. Dhruv Metals manufactures bars and rods that satisfy international standards for demanding industrial applications by using sophisticated forging techniques and stringent quality control. To accommodate a broad range of mechanical, structural, and corrosive environments, their products come in a variety of stainless steel grades and dimensions. Dhruv Metals, which serves the oil and gas, construction, marine, and automotive industries, is dedicated to providing dependable forged components that meet the needs of individual customers.
The basic elements of stainless steel forged bars and rods are usually iron, nickel (8–14%), molybdenum (0–3%), and chromium (16–20%). Depending on the grade (e.g., 304, 316, 410), additional elements may include manganese, silicon, and carbon. These bars have outstanding strength, heat tolerance, and corrosion resistance. In terms of mechanics, they offer elongation of up to 40%, yield strength of 200–500 MPa, and tensile strength of 500–750 MPa. Superior mechanical performance for high-stress and precision-driven industrial applications is achieved through forging, which enhances grain structure and impact resistance.
Standards : ASTM A276, ASTM A484, AISI
Grade : 201, 202, 301, 302, 303, 304, 304H, 304L, 316, 316H, 316L, 309, 309S, 310, 310S, 316Ti, 317, 317L, 347, 321, 321H, 410, 416, 420, 430, 430F, 431, 440C, 630, 17-4PH, F51
Range : from 2.00mm to 6.35mm (0.078″ to 0.25″)dia.
Tolerance : DIN 671, ASTM A484 & as per customer’s specific requirement.
Finish : Cold drawn, Centreless Ground, Polished
| Grade | Su | C | Si | P | Cr | Ni | M | Mo | Other |
|---|---|---|---|---|---|---|---|---|---|
| 316 | 0.030 max | 0.08 max | 0.75 max | 0.045 max | 16.0-18.0 | 10.0 14.0 | 2.00 max | 2.0 3.0 | – |
| 317L | 0.030 max | 0.035 max | 0.75 max | 0.045 max | 18.0-20.0 | 11.0 14.0 | 2.00 max | 3.0 4.0 | – |
| 304 | 0.030 max | 0.08 max | 0.75 max | 0.045 max | 18.0-20.0 | 8.0 11.0 | 2.00 max | – | – |
| 310 S | 0.030 max | 0.08 max | 1.5 max | 0.045 max | 24.0-26.0 | 19.0 22.0 | 2.00 max | 3.0 4.0 | – |
| 347 H | 0.030 max | 0.04 0.10 | 0.75 max | 0.045 max | 17.0- 19.0 | 9.0 13.0 | 2.00 max | – | 10C(Cb+Ta)<1.10% |
| 321 | 0.030 max | 0.08 | 0.75 max | 0.045 max | 17.0-20.0 | 9.0 12.0 | 2.00 max | – | 5C 0.70% |
| Grade | Tensile Strength | Yield Strength (0.2%Offset) | Density | Elongation | Melting Point |
|---|---|---|---|---|---|
| SS 303 | Psi – 85,000 | Psi – 45,000 | 55% | 50 % | Rb 180 |
| SS 202 | 515 MPa | 275 MPa | 8.0 g/cm3 | 40 % | 1454 °C |
| SS 304 | Psi – 75000 , MPa – 515 | Psi – 30000 , MPa – 205 | 8.0 g/cm3 | 40% | 1400 °C |
| SS 304L | Psi – 75000 , MPa – 515 | Psi – 30000 , MPa – 205 | 8.0 g/cm3 | 40% | 1400 °C |
| SS 316 | Psi – 75000 , MPa – 515 | Psi – 30000 , MPa – 205 | 8.0 g/cm3 | 35 % | 1454 °C |
| SS 316L | 485 Min | 170 Min. | 8.0 g/cm3 | 40 % | 1400 °C |
| Type | Peeled nd Ground | Cold Drawn and Polish | Peeled and Polished | Cold Drawn and Ground |
|---|---|---|---|---|
| Sizes (mm) | 20.00 – 50.00 | 3.00 to 75.00 | 40.00 – 150.00 | 10.00 to 75.00 |
| Sizes (inch) | 3/4 – 2.00 | 1/8 to3.00 | 1.50 – 6.00 | 5/6 to 2.50 |
| Tolerance | h9 to h11 | h8 to h11 | h11, h11-DIN 1013 | h8 to h11 |
| CD | CF | CG | BD | ST | P&T |
|---|---|---|---|---|---|
| Cold drawn | Cold finished | Centreless ground | Bright drawn | Smooth turned | Peeled and turned |
| P | HRAP | HF | SRE | PR | RT |
| Polished | Hot rolled annealed and pickled | Hot finished | Slit rolled edge | Peeled and reeled | Rough turned/peeled |
Many industries that need strong, corrosion-resistant, and high-strength components use stainless steel forged bars and rods. They are used in pipeline supports, drill collars, shafts and valves in the oil and gas industry. They are used in foundation rods, fasteners, and structural supports in the building sector. Because they don’t corrode in seawater, they are perfect for rigging, deck components, and propeller shafts in maritime settings. They are also utilised in the food processing and pharmaceutical industries for hygienic and sanitary components, as well as in the automotive industry for axles, gears, and crankshafts. They are essential in heavy-duty applications due to their dependability and durability.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
