Dhruv Metals, a prominent manufacturer and supplier located in Hyderabad, India, specializes in providing high-quality Stainless Steel Hex Bars and Rods suitable for a variety of industrial and commercial uses. Renowned for our precision manufacturing, exceptional surface finish, and high dimensional accuracy, we create our hex bars and rods from top-grade stainless steel to guarantee strength, corrosion resistance, and long-lasting durability. With a strong dedication to quality and timely delivery, Dhruv Metals caters to a wide range of industries, offering products that adhere to international standards and perform reliably in both standard and high-stress environments.
Our Stainless Steel Hex Bars and Rods are typically made from grades like 304, 316, 321, and others, tailored to meet specific mechanical and corrosion-resistant needs. These bars have a six-sided cross-section and are primarily composed of iron, chromium (≥10.5%), nickel, and trace elements such as molybdenum or titanium to boost performance. The mechanical properties differ by grade, with tensile strengths ranging from 500 to 750 MPa, yield strengths between 200 and 450 MPa, and elongation around 30–35%. Their unique shape provides excellent machinability and strength, making them perfect for fasteners, valves, and precision components.
| Name | Stainless Steel Hexagonal Bars |
| Stainless Steel Hex Bar Standard | EN, AISI, DIN, ASTM, SUS |
| Grades | 304L, 201, 202, 301, 304LN, 309S, 17L, 347, 347H, 316N, 316LN, 304, 316, 316L, 317,3 304N 310S, 316Ti, |
| Stainless Steel Hex Bar Size (Hexagonal bar) | 6 x 6 milimeter to 75 x 75 milimeter |
| Shape | Stainless steel hexagonal bar |
| Price Term | CIF/FOB/CNF or as per need |
| Stainless Steel Hex Bar Length | 5MTR, 4MTR, 6MTR, 3MTR or as per need |
| Application | Architectural Applications, Kitchen Equipment , Sanitary Wares, Furniture, Precision Engineering |
| Stainless Steel Hex Bar Certificate | NDT Test Reports, NABL Approved Lab Test Reports, IGC Practice E Test Reports, Mill TC EN 10204 3.1, |
| Grade | Si | C | Mn | Cr | Ni | N | S | P |
| SS 304 | 0.75 max | 0.03 max | 2 max | 18 – 20 | 8 – 12 | 0.10 Max | 0.030 max | 0.045 max |
| SS 304L | 0.75 max | 0.03 max | 2 max | 18 – 20 | 8 – 12 | 0.10 Max | 0.030 max | 0.045 max |
| SS 316 | 0.75 max | 0.08 max | 2 max | 15 – 18 | 10 – 14 | 0.1 Max | 0.030 max | 0.045 max |
| SS 316L | 0.75 max | 2.00 max | 18.00 max | 14.00 Max | 0.10 Max | 0.1 Max | 0.030 max | 0.045 max |
| Grade | Tensile Strength | Yield Strength (0.2%Offset) | Elongation | Density | Melting Point |
| SS 304 | Psi – 75000 , MPa – 515 | Psi – 30000 , MPa – 205 | 40% | 8.0 g/cm3 | 1400 °C (2550 °F) |
| SS 304L | Psi – 75000 , MPa – 515 | Psi – 30000 , MPa – 205 | 40% | 8.0 g/cm3 | 1400 °C (2550 °F) |
| SS 316 | Psi – 75000 , MPa – 515 | Psi – 30000 , MPa – 205 | 35 % | 8.0 g/cm3 | 1454 °C (2650 °F) |
| SS 316L | 485 Min | 170 Min. | 40 % | 8.0 g/cm3 | 1400 °C (2550 °F) |
| Length in inch | Size in Inch | Weight (lbs/ft) |
|---|---|---|
| 144 | 1/4 | .180 |
| 3/8 | .415 | |
| 7/16 | .565 | |
| 1/2 | .735 | |
| 9/16 | .930 | |
| 5/8 | 1.15 | |
| 11/16 | 1.390 | |
| 3/4 | 1.655 | |
| 7/8 | 2.255 | |
| 1 | 2.945 | |
| 1-1/16 | 3.31 | |
| 1-1/8 | 3.73 | |
| 1-1/4 | 4.60 | |
| 1-3/8 | 5.58 | |
| 1-1/2 | 6.63 | |
| 1-5/8 | 7.78 | |
| 2 | 11.79 | |
| 4 | 47.160 |
| Sizes in Inch | Stainless Steel Hex Bar Sizes In inch |
| H-1/8 | 1/8 |
| H-1/4 | 1/4 |
| H-5/32 | 5/32 |
| H-3/16 | 3/16 |
| H-7/32 | 7/32 |
| H-5/16 | 5/16 |
| H-3/8 | 3/8 |
| H-7/16 | 7/16 |
| H-7/8 | 7/8 |
| H-1/2 | 1/2 |
| H-9/16 | 9/16 |
| H-5/8 | 5/8 |
| H-11/16 | 11/16 |
| H-3/4 | 3/4 |
| H-1 | 1 |
| H-1-1/8 | 1-1/8 |
| H-1-1/4 | 1-1/4 |
| H-2 | 2 |
| H-1-3/8 | 1-3/8 |
| H-1-1/2 | 1-1/2 |
| H-1-5/8 | 1-5/8 |
| H-1-3/4 | 1-3/4 |
| H-1-7/8 | 1-7/8 |
| H-2-1/4 | 2-1/4 |
| H-2-3/4 | 2-3/4 |
| H-2-1/2 | 2-1/2 |
| H-3 | 3 |
| Section | Size, diameter | Permitted overall variation | ||
| Class A | Class B | Class C | ||
| mm | mm | mm | mm | |
| Round | ≧ 6 <75 | 0.05 | 0.025 | 0.013 |
Stainless steel hex bars and rods come in various grades, including 304, 316, 410, 416, 420, and 630. They vary in corrosion resistance, strength, and hardness. Common types include austenitic, ferritic, martensitic, and precipitation-hardening stainless steels, each suited for different applications in manufacturing, construction, and marine environments.
In the India, you can buy high-quality stainless steel (SS) hex bars and rods from suppliers such as Metal Supermarkets, 304 Stainless Steel, or Aalco Metals. They offer a wide selection of sizes and grades. Other reputable suppliers include Buy Metal Online, Steel Express, and India Steel. Ensure to check their specifications for the exact product you need.
Yes, many India suppliers offer 316 stainless steel hex bars and rods in custom sizes and finishes. Companies like Metal Supermarkets, Buy Metal Online, and Steel Express provide tailored options, including specific lengths, diameters, and polished finishes. Contacting the supplier directly allows you to request personalized products to meet your specific requirements for projects.
Stainless Steel Hex Bars and Rods are extensively utilized across various industries due to their impressive strength, corrosion resistance, and ease of fabrication. In the automotive and aerospace fields, they are essential for producing bolts, nuts, shafts, and structural components. In the chemical and marine sectors, their corrosion resistance makes them ideal for fittings, valves, and pump parts that face harsh conditions. They are also widely used in construction, food processing, and machinery manufacturing. The hexagonal shape enhances grip and torque, making them a favored option for precision machining and fastening tasks.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
