Dhruv Metals, a well-respected name in Hyderabad, India, stands out as a top manufacturer and supplier of high-quality Titanium Grade 2 Forgings, crafted to meet the toughest industrial standards. Renowned for their precision, strength, and resistance to corrosion, these forgings are perfect for use in aerospace, marine, chemical processing, and medical fields. Dhruv Metals employs cutting-edge forging techniques and strict quality control measures to create Titanium Gr 2 components in a variety of shapes and sizes, customized to meet customer needs. With a solid reputation for timely delivery and technical expertise, Dhruv Metals provides reliable titanium solutions for clients both locally and globally.
Titanium Grade 2 is a commercially pure titanium alloy (UNS R50400) that consists of 99.2% titanium, along with small amounts of iron, oxygen, carbon, nitrogen, and hydrogen. It boasts a fantastic balance of strength (with tensile strength ranging from ~344 to 552 MPa) and ductility, along with exceptional corrosion resistance in oxidizing and mildly reducing environments. The density is around 4.51 g/cm³, and it offers good weldability, formability, and impact resistance. Titanium Gr 2 forgings maintain their structural integrity across various temperatures, making them ideal for applications that require both lightweight and durable performance.
| Specifications | ASTM B381, ASME SB381 |
|---|---|
| Standard | DIN, ASTM, BS and all International Standards |
| Flat bar blocks | up to 27″ width and 15,000 lbs |
| Cylinders and sleeves | up to 50″ maximum O.D. and 65″ maximum length |
| Discs and hubs | up to 50″ diameter and 20,000 lbs |
| Rolled, hand forged or mandrel forged rings | up to 84″ maximum O.D. and 40″ maximum length |
| Rounds, shafts and step shafts | up to 144″ maximum length and 20,000 lbs |
| Forging Types | Impression Die Forging, Open Die Forging, Seamless Rolled Forging, Hot Forging, Cold Forging, Open die hammer forging, Impression die drop forging, Closed Die Forging, Press Forging, Upset Forging, Compression Forging, Swaging, Rotary Forging, Roll forging. |
| Grade | Ti | C | Fe | H | N | O | Al | V |
| ASTM B381 R50400 | 99.2 min | 0.1 max | 0.3 max | 0.015 max | 0.03 max | 0.25 max | – | – |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Titanium Gr. 2 | 4.5 g/cm3 | 1665 °C (3030 °F) | Psi – 49900 , MPa – 344 | Psi – 39900 , MPa – 275 | 20 % |
| STANDARD | WERKSTOFF NR. | UNS |
| Titanium Gr. 2 | 3.7035 | R50400 |
Titanium Gr 2 Forgings find extensive use in the aerospace industry for aircraft components, frames, and fasteners, thanks to their impressive strength and low weight. In the chemical sector, they are perfect for valves, flanges, and fittings that need to endure corrosive substances like chlorides and acids. The marine industry relies on these forgings for ship parts and offshore platforms that face saltwater exposure. In medical settings, Titanium Gr 2 is utilized for surgical instruments and orthopedic implants due to its biocompatibility. Additionally, they play a role in power generation, desalination, and heat exchanger systems.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Dhruv Metals is a leading manufacturer, supplier, and exporter of high-quality bars, rods, and forgings, catering to various industries in Hyderabad , India
