Dhruv Metals, located in Hyderabad, India, has made a name for itself as a leading manufacturer and supplier of Titanium Grade 7 Forgings. These forgings are celebrated for their outstanding corrosion resistance and structural integrity. Crafted to meet ASTM B381 specifications, they’re perfect for use in highly corrosive environments. Titanium Grade 7, which is stabilized with palladium, provides enhanced protection against reducing acids and chloride-rich solutions. With a strong focus on quality control and precision engineering, Dhruv Metals delivers forgings that comply with both national and international standards. Their dedication to innovation, reliability, and customer satisfaction has established them as a trusted partner in the chemical, marine, and power generation sectors.
The Titanium Grade 7 Forgings from Dhruv Metals are primarily made up of Titanium (≥ 99.1%), with Palladium (0.12%–0.25%) included to boost corrosion resistance. They also contain small amounts of iron, oxygen, nitrogen, carbon, and hydrogen. These forgings showcase impressive mechanical strength, featuring a tensile strength of ≥ 345 MPa, yield strength of ≥ 275 MPa, and an elongation of ≥ 20%. With a density of 4.51 g/cm³, they perform exceptionally well in harsh chemical environments, particularly at high temperatures. Grade 7 combines the mechanical advantages of Grade 2 with superior corrosion protection, making it perfect for critical applications.
| Specifications | ASTM B381, ASME SB381 |
|---|---|
| Standard | DIN, ASTM, BS and all International Standards |
| Flat bar blocks | up to 27″ width and 15,000 lbs |
| Cylinders and sleeves | up to 50″ maximum O.D. and 65″ maximum length |
| Discs and hubs | up to 50″ diameter and 20,000 lbs |
| Rolled, hand forged or mandrel forged rings | up to 84″ maximum O.D. and 40″ maximum length |
| Rounds, shafts and step shafts | up to 144″ maximum length and 20,000 lbs |
| Forging Types | Impression Die Forging, Open Die Forging, Seamless Rolled Forging, Hot Forging, Cold Forging, Open die hammer forging, Impression die drop forging, Closed Die Forging, Press Forging, Upset Forging, Compression Forging, Swaging, Rotary Forging, Roll forging. |
| Grade | C | N | O | H | Ti | Fe | Al | Pd |
| Titanium Gr 7 | 08 max | 03 max | 25 max | 015 max | Bal | 0.30 max | – | .12 – .25 |
| 0.2% Proof Stress MPa | Tensile Strength MPa | Elongation % |
| 275-475 | 345 | 20 |
| STANDARD | WERKSTOFF NR. | UNS |
| Titanium Gr. 7 | 3.7235 | R52400 |
Titanium Gr 7 Forgings are predominantly utilized in the chemical processing industry, especially in settings that involve highly corrosive substances like hydrochloric, nitric, and sulfuric acids. Their remarkable resistance to crevice corrosion and stress corrosion cracking makes them ideal for heat exchangers, reactors, piping systems, and pressure vessels. In the marine industry, they are commonly used in seawater handling systems and desalination plants. Additionally, these forgings are valuable in power generation, particularly in condenser applications, where their durability and reliability are essential for optimal performance.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Dhruv Metals is a leading manufacturer, supplier, and exporter of high-quality bars, rods, and forgings, catering to various industries in Hyderabad , India
