Dhruv Metals is a reliable manufacturer and supplier of top-notch Titanium Grade 6 Bars and Rods, proudly based in Hyderabad, India. With years of expertise and a strong commitment to quality, Dhruv Metals provides titanium products that adhere to global standards for performance and durability. Our Titanium Grade 6 (Ti-5Al-2.5Sn) bars and rods are celebrated for their impressive strength, resistance to corrosion, and long-lasting reliability. We cater to a variety of industries, including aerospace, marine, and chemical processing, offering tailored solutions and prompt delivery to clients both in India and around the world.
Titanium Grade 6 (Ti-5Al-2.5Sn) is an alpha alloy primarily made up of Titanium, along with 5% Aluminum and 2.5% Tin. It boasts good weldability, moderate to high strength, and outstanding oxidation resistance at elevated temperatures. Typical mechanical properties include a tensile strength of about 895 MPa, yield strength of roughly 827 MPa, hardness around 240 HB, and elongation between 10–15%. These characteristics make Titanium Grade 6 an excellent choice for demanding structural applications that require both lightweight materials and resilience.
| Standards : | ASTM B348, B863 / ASME SB348, SB863 |
| Dimensions : | EN, DIN, JIS, ASTM, BS, ASME, AISI |
| Wire : | Thickness starting from 0.05mm |
| Round bar size : | Diameter: 3-~800mm |
| Hex Bar size : | 2-100mm A/F |
| Flat bar size : | Thickness: 2 -100mm / Width: 10 to 500mm |
| Square bar size : | 4 to 100mm |
| Rectangular Bars Size : | 33 x 30mm to 295 x 1066mm |
| Hollow Bar : | 32mm OD x 16mm ID to 250mm OD x 200mm ID |
| Tolerance : | H8, H9, H10, H11, H12, H13K9, K10, K11, K12 or as per clients’ requirements |
| Finish : | Black, Bright Polished, Rough Turned, NO.4 Finish, Matt Finish, BA Finish |
| STANDARD | WERKSTOFF NR. | UNS |
| Titanium Gr 6 | 3.7114 | R54520 |
| Grade | C | Fe | N | Ti | H | O | Al | Sn |
| Titanium Gr. 6 | .08 max | 0.50 max | .05 max | Balance | .0175 – .020 | .20 max | 4.0 – 6.0 | 2.0 – 3.0 |
| Element | Min.Tensile(KSI) | Min.Yield(KSI) | Hardness | Tensile Modulus | Poisson’s Ratio |
| Ti Grade 6 | 50 | 40 | 14.9 | 103 GPa | 0.34-0.10 |
| Type | SIZES (mm) | SIZES (Inches) | ISO Tolerance |
|---|---|---|---|
| Cold Drawn and Ground | 10.00 – 75.00 | 5/6″ – 2.50″ | h8-h9-h10-h11 |
| Peeled and Polished | 40.00 – 150.00 | 1.50″ – 6.00″ | h11, h11-DIN 1013 |
| Peeled and Ground | 20.00 – 50.00 | 3/4″ – 2.00″ | h9-h10-h11 |
| Cold Drawn and Polish | 3.00 – 75.00 | 1/8″ – 3.00″ | h8-h9-h10-h11 |
Titanium Grade 6 Bars Standard lengths of 2000 mm up to 6000 mm. Cut to size on request (tolerance +2/-0 mm).
| 5.0 | 45.0 |
| 6.0 | 50.0 |
| 7.0 | 55.0 |
| 8.0 | 60.0 |
| 9.0 | 65.0 |
| 10.0 | 70.0 |
| 12.0 | 75.0 |
| 16.0 | 80.0 |
| 20.0 | 90.0 |
| 25.0 | 100.0 |
| 30.0 | 130.0 |
| 35.0 | 160.0 |
| 40.0 | 200.0 |
Yes, we provide bars and rods in standard and customized dimensions and polishes to meet your specific project requirements. For more details mail us on sales@dhruvmetals.co.in
Titanium Grade 6 Bars and Rods provide excellent strength-to-weight ratio, outstanding corrosion resistance, high-temperature stability, and good formability, making them ideal for high-performance applications.
Titanium Grade 6 Bars and Rods offer superior strength, corrosion resistance, and weldability, along with excellent performance in high-temperature and aggressive environments, making them suitable for critical industrial applications.
Titanium Grade 6 Bars and Rods are extensively utilized in aerospace components like airframes, engine parts, and hydraulic systems, thanks to their high strength-to-weight ratio and fatigue resistance. In marine settings, they are perfect for applications such as shafts, propellers, and fasteners that are constantly exposed to saltwater. The chemical processing industry employs them in heat exchangers, reactors, and piping systems due to their corrosion and oxidation resistance. Additionally, they are used in medical implants, power generation equipment, and automotive parts, where strength, weight reduction, and long-term performance are essential.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
